On Roof Sheet Area
₹255 / sq.ftCost inclusive of materials and labour. GST extra.
Factory Shed Manufacturer in Kolkata • 6 Meter Height • With Crane
6 Meter Industrial Shed with Crane in Kolkata
CND Engineering Pvt Ltd provides crane-supported 6 meter industrial shed, factory shed and PEB shed solutions for production units, warehouses, workshops, material handling zones and manufacturing operations across Kolkata and West Bengal.
This model gives buyers clear rate visibility, roof and vertical cladding cost references, material specification and budget guidance before detailed engineering and final quotation.
ShadeFab is the online product and enquiry platform for CND Engineering Pvt Ltd industrial shed, PEB shed, crane shed, roofing and cladding enquiries.
Commercial Snapshot
6m Height with Crane
Roof Sheet Area₹255 / sq.ft
Vertical Cladding₹120 / sq.ft
Reference Area10,000 sq.ft
Cost inclusive of materials and labour. GST extra. Final quote depends on site and crane details.
Complete Technical-Sales Visual
Crane-Enabled Industrial Shed: Cost, Material and Structural Details
The visual is placed as the central product image so the buyer can quickly understand crane provision, material specification, roof sheet rate, cladding rate and approximate budget.
Project Overview
Factory shed solution for businesses needing crane-supported operations.
This industrial shed model is designed for businesses that need a 6 meter height shed with crane provision. It is suitable for factory operations, material movement, workshop activity, production support and storage applications.
The package gives clear commercial visibility with separate rates for roof sheet area and vertical cladding, making it easier for owners, purchase teams and project heads to evaluate the shed before detailed engineering consultation.
Project Parameters
Shed HeightUp to 6 Meter
Crane ProvisionWith Crane
Reference Area10,000 sq.ft
Roof Sheet0.45 mm PPGL Sheet
Application Fit
6m crane shed for factories, warehouses and workshops
A crane-supported industrial shed needs better structural planning than a general roof shed. Column selection, truss design, purlin layout, base plate detailing, crane movement and vertical clearance must be considered before finalizing the estimate.
This 6 meter crane shed solution is suitable for light-to-medium industrial operations where internal lifting, material loading, production handling or workshop movement is required.
Suitable Uses
- Factory shed with material handling requirement
- Warehouse shed with crane-supported movement
- Workshop shed for fabrication or maintenance activity
- Production shed with internal lifting provision
- Industrial storage shed with roofing and cladding
- PEB shed with practical cost and material visibility
Competitive Pricing
Transparent commercial structure for industrial decision-makers.
Simple rate visibility helps owners, project heads and purchase teams evaluate the shed cost quickly. These figures are reference rates and must be confirmed against project scope, site condition and final technical details.
On Vertical Cladding
₹120 / sq.ftFor enclosure, protection and exterior factory shed finish.
Floor Area Reference
10,000 sq.ftUsed as the reference area for approximate budget planning.
Materials Details
Technical specification for the crane-supported 6 meter shed.
The material schedule is designed to support the higher structural demand of a factory shed with crane provision. Final member sizes may vary after engineering review, soil/site inputs and crane load confirmation.
ColumnISMB 350
TrussRHS 80 × 40 × 2.6, SHS 40 × 40 × 2
PurlinRHS 80 × 40 × 2.6
Base Plate16 mm
Roof Sheet0.45 mm PPGL Sheet
Cost Factors
What affects 6 meter crane shed cost?
The quoted rate can change based on crane capacity, foundation requirement, site access, roof sheet area, cladding height, transportation and execution scope.
Crane Capacity
Higher crane load requires stronger planning for columns, supports, movement clearance and operational safety.
Span and Bay Spacing
Clear span and bay spacing influence steel weight, fabrication details and erection planning.
Roof and Cladding Area
Actual roof sheet area, side cladding height, flashing, gutter and downpipe scope affect final cost.
Approximate Total Budget
Budget clarity for roof and vertical cladding.
For Roof₹27,54,000/-
For Vertical Cladding₹7,08,000/-
Final quotation may vary based on site condition, crane details, structural drawing, transportation, foundation requirement, finishing scope and GST.
Why crane provision matters
- Supports material movement inside the factory shed.
- Improves workflow efficiency for production or fabrication units.
- Requires stronger column and structural specification.
- Helps businesses plan long-term industrial operations.
Execution Process
Structured process for crane shed planning and execution
We review site location, area, height, usage, span, crane requirement and roof/cladding need.
Column, truss, purlin, base plate, roof sheet and crane movement factors are checked.
Roof sheet area, vertical cladding and project scope are aligned for quotation clarity.
Material, handling, supply and installation sequence are organized for site practicality.
Erection, sheet fixing, cladding and finishing are coordinated for reliable completion.
CND Engineering Advantage
Built for serious industrial buyers who need durability, reliability and execution confidence.
Bespoke Factory Shed
Designed around industrial use, handling needs and site requirements.
Crane-Ready Planning
Structural specification supports factory operation and material movement.
Transparent Pricing
Clear roof and cladding costs help buyers decide faster.
Quality Execution
Focused on durable materials, timely delivery and dependable fabrication.
Service Areas
6m industrial shed with crane in Kolkata and West Bengal
CND Engineering supports crane shed, factory shed, industrial shed, roofing and vertical cladding requirements across Kolkata and major industrial locations of West Bengal.
FAQ
Frequently asked questions about 6m crane sheds
What is the rate for a 6 meter industrial shed with crane?
The reference rate is ₹255 per sq.ft on roof sheet area and ₹120 per sq.ft for vertical cladding, inclusive of materials and labour. GST and project-specific items are extra.
What materials are used in this crane shed model?
The reference specification includes ISMB 350 columns, RHS and SHS truss members, RHS purlins, 16 mm base plate and 0.45 mm PPGL roof sheet.
What information is needed for quotation?
Share site location, floor area, required height, crane capacity, span, usage, roof sheet area, vertical cladding requirement and expected timeline.
Which locations does CND Engineering serve?
CND Engineering serves Kolkata, Howrah, Hooghly, North 24 Parganas, South 24 Parganas, Haldia, Durgapur, Kharagpur and other industrial locations in West Bengal and Eastern India.
Build Your Next Industrial Asset
Need a crane-supported factory shed quotation?
Share your shed size, crane requirement, location and usage type. Our team will guide you with the right technical and commercial solution.
