On Roof Sheet Area
₹295 / sq.ftFor 9 meter industrial shed with crane provision based on the reference project size.
Warehouse Shed Fabricator in Kolkata
Industrial Shed up to 9 Meter Height With Crane
Explore durable warehouse shed solutions tailored to your needs. CND Engineering delivers quality structures for efficient storage, smooth operations and overhead crane-enabled industrial workflow.
9 MeterShed Height
With CraneOverhead crane provision
10,000 sq.ftReference floor area
0.50 mm PPGLRoof sheet specification
Complete Technical-Sales Image
Crane-Ready Industrial Shed with Pricing, Materials and Cross Section
The product visual below uses the correct 9 meter with crane shed image and presents the main commercial and technical specifications for quick buyer understanding.
Project Overview
Crane-enabled warehouse shed for efficient storage and operations.
This industrial shed model is designed for businesses that require a 9 meter height warehouse shed with overhead crane provision. It supports material movement, fabrication workflow, storage efficiency and industrial operations where clear height and crane access matter.
CND Engineering, the fabricator of warehouse sheds in Kolkata, provides durable structures, practical planning and technical clarity for serious industrial buyers.
Application Fit
- Warehouse and storage facilities
- Factory and workshop operations
- Steel fabrication and handling zones
- Material movement using overhead crane
- Industrial asset expansion projects
Transparent Pricing
Competitive commercial structure with clear rate visibility.
Cost inclusive of materials and labours. GST extra.
On Vertical Cladding
₹120 / sq.ftFor external side coverage, protection and warehouse shed enclosure.
Reference Area
10,000 sq.ftUsed for approximate total budget communication and buyer discussion.
Material Details
Technical specification for 9 meter industrial shed with crane.
The following material specification supports a crane-enabled warehouse shed structure with defined steel members, base plate and PPGL roof sheet details.
ColumnISMC 150 Batten using 6 mm MS plate
TrussRHS 96 × 48 × 2.6, SHS 40 × 40 × 2
PurlinRHS 96 × 48 × 2.6
Base Plate16 mm
Roof Sheet0.50 mm PPGL Sheet
Approximate Total Budget
Budget breakup for roof and vertical cladding.
For Roof₹31,86,000/-
For Vertical Cladding₹11,64,960/-
Final quotation may vary based on site condition, crane specification, structural drawing, transportation, foundation requirement, finishing scope and GST.
Why overhead crane provision matters
- Improves internal material movement and handling efficiency.
- Supports warehouse, fabrication and heavy workflow operations.
- Requires better structural planning and specification clarity.
- Creates long-term operational value for industrial businesses.
Execution Roadmap
From technical requirement to site-ready industrial asset.
01Requirement Review
Understand floor area, crane need, shed height and industrial usage.
02Technical Scope
Finalize roof sheet, cladding, column, truss and purlin specification.
03Budget Planning
Prepare roof and vertical cladding estimate with commercial clarity.
04Execution Support
Coordinate fabrication, delivery, installation and project workflow.
CND Engineering Advantage
Durable warehouse shed solutions for serious industrial buyers.
Custom Design
Tailored warehouse shed planning based on your business operation.
Quality Structures
Defined material schedule for dependable shed fabrication.
Efficient Operations
Crane provision supports smoother internal movement and productivity.
Cost Clarity
Clear roof and cladding rates support faster project decisions.
Build Strong. Build Smart.
Need a 9 meter warehouse shed with crane?
Share your floor area, site location, crane requirement and operational need. Our team will guide you with the right technical and commercial solution.
