On Roof Sheet Area
₹255 / sq.ftFor roof sheet area work based on the 10,000 sq.ft reference model.
Industrial Shed Manufacturer in Kolkata • 9 Meter Height • Without Crane
9 Meter Industrial Shed Without Crane in Kolkata
CND Engineering Pvt Ltd provides 9 meter industrial shed, factory shed and warehouse shed solutions for storage facilities, production support areas, workshops, logistics units and industrial expansion projects across Kolkata and West Bengal.
This model is designed for businesses that need better vertical clearance without crane provision. It gives buyers transparent roof sheet area pricing, vertical cladding rates, material specification and approximate budget guidance before final engineering consultation.
ShadeFab is the online product and enquiry platform for CND Engineering Pvt Ltd industrial shed, PEB shed, factory shed, roofing and cladding enquiries.
Technical Sales Visual
9 Meter Industrial Shed — Specification, Cost and Material Details
The main infographic helps buyers understand roof sheet rate, cladding rate, material specification, approximate budget and the without-crane shed model at a glance.
9 MeterShed Height
Without CraneSpecified Shed Model
10,000 sq.ftReference Floor Area
0.45 mm PPGLRoof Sheet
Project Overview
Robust industrial shed solution for factories, warehouses and storage needs.
This shed model is designed for businesses requiring a 9 meter height industrial structure without crane provision. It supports industrial storage, factory expansion, material movement, light production, workshop activity and warehouse-type applications where vertical clearance is important.
CND Engineering focuses on customized solutions, quality craftsmanship and reliability so buyers can plan industrial infrastructure with confidence. The separate roof and cladding rate structure helps owners, consultants and purchase teams evaluate the project commercially before site-specific design and quotation.
Key Parameters
Nature of ShedIndustrial Shed
HeightUp to 9 Meter
CraneWithout Crane
Floor Area10,000 sq.ft
Application Fit
9m industrial shed for storage, production support and warehouse use
A 9 meter industrial shed without crane is useful when the buyer needs additional height for storage, equipment clearance, ventilation, loading movement or future service additions, but does not need crane-supported handling. This makes the model cost-conscious while still providing strong operational utility.
The structure should be planned with proper column placement, roof slope, purlin spacing, rainwater drainage, cladding height, vehicle access and future expansion possibility. A well-planned 9m shed can reduce maintenance issues and improve long-term usability.
Suitable Uses
- Factory expansion shed without crane provision
- Warehouse shed with higher vertical clearance
- Workshop shed for light industrial activity
- Storage shed for materials, packaging or inventory
- Production support shed with roofing and cladding
- Cost-focused steel structure for industrial sites
Pricing Structure
Competitive costing with clear roof and cladding rates.
Cost is shown in a buyer-friendly format for quick initial evaluation. Final quotation should be confirmed after site details, drawing, cladding height, transportation and execution scope are reviewed.
On Vertical Cladding
₹120 / sq.ftFor side enclosure, weather protection and industrial external finish.
Reference Area
10,000 sq.ftUsed for approximate budgeting, comparison and buyer discussion.
Material Details
Technical specification for 9 meter height without crane.
The material schedule is clearly listed so technical and commercial buyers can understand the structural scope, roof specification and supporting steel members. Final sizing may vary after engineering review, site inputs and execution requirements.
ColumnISMB 350
TrussRHS 80 × 40 × 2.6, SHS 40 × 40 × 2
PurlinRHS 80 × 40 × 2.6
Base Plate16 mm
Roof Sheet0.45 mm PPGL Sheet
Cost Factors
What affects 9 meter industrial shed cost?
Reference rates help initial comparison, but the final cost depends on project-specific engineering, material and site-execution conditions.
Height and Span
A 9 meter height structure needs appropriate member selection, bracing and erection planning for stability and usability.
Cladding Scope
Vertical cladding height, side coverage, flashing, gutters and downpipes influence the final commercial scope.
Site Conditions
Access road, storage space, transportation distance, foundation readiness and local labour movement affect execution cost.
Approximate Total Budget
Budget breakup for roof and vertical cladding.
For Roof
₹27,54,000/-
For Vertical Cladding
₹11,64,960/-
Final quotation may vary depending on site condition, engineering drawing, transportation, foundation requirement, finishing scope, cladding coverage and GST.
Why this shed model works
- Strong 9 meter height for better vertical clearance.
- Designed without crane for cost-efficient industrial use.
- Clear material schedule and transparent commercial structure.
- Suitable for factories, warehouses and business expansion.
Execution Process
Structured process for 9m industrial shed planning
We review site location, floor area, usage, height, clear span and cladding need.
Column, truss, purlin, roof slope, sheet and drainage details are checked.
Roof sheet area, vertical cladding and project scope are aligned for quotation clarity.
Material, handling, supply and installation sequence are organized for site practicality.
Erection, sheet fixing, cladding and finishing are coordinated for reliable completion.
CND Engineering Advantage
Customized industrial shed solutions with reliable execution.
Customized Solutions
Tailored shed design based on business and site requirements.
Quality Craftsmanship
Defined material details and robust structural planning.
Reliable Support
Kolkata-based industrial shed manufacturing support.
Cost Effective
Clear rates help buyers evaluate project feasibility quickly.
Service Areas
9m industrial shed without crane in Kolkata and West Bengal
CND Engineering supports factory shed, warehouse shed, industrial shed, roofing and vertical cladding requirements across Kolkata and major industrial locations of West Bengal.
FAQ
Frequently asked questions about 9m industrial sheds
What is the rate for a 9 meter industrial shed without crane?
The reference rate is ₹255 per sq.ft on roof sheet area and ₹120 per sq.ft for vertical cladding, inclusive of materials and labour. GST and project-specific items are extra.
What materials are used in this 9m shed model?
The reference specification includes ISMB 350 columns, RHS and SHS truss members, RHS purlins, 16 mm base plate and 0.45 mm PPGL roof sheet.
What information is needed for quotation?
Share site location, floor area, required height, clear span, usage, roof sheet area, vertical cladding requirement and expected timeline.
Which locations does CND Engineering serve?
CND Engineering serves Kolkata, Howrah, Hooghly, North 24 Parganas, South 24 Parganas, Haldia, Durgapur, Kharagpur and other industrial locations in West Bengal and Eastern India.
Get Industrial Shed Quotation
Ready to discuss your 9 meter industrial shed requirement?
Share floor area, site location, usage type and cladding requirement. Our team will guide you with the right technical and commercial solution.
