SHS Structure
Columns, truss and purlins are designed with square hollow sections for a neat and strong framework.
Premium Storage Roof Shed · Kolkata
Customized 1500 Sq Ft Roof Shed Installation in Kolkata
CND Engineering Pvt Ltd provides efficient and customized storage roof shed designs for organized, accessible spaces. This 1500 sq ft model is built with SHS tubular structure, 0.45 mm PPGL roof sheet, 600 mm vertical dropping on all four sides, and an externally routed water outlet system.
Get WhatsApp Quote
Approximate Total Budget
₹2,75,625/-
For Roof · GST Extra
Materials + Labour Included
Full-width product image kept clean with no text overlay, so the complete shed and upper roof portion remain clearly visible.
Designed for protection, storage and long-term roof utility
CND Engineering is a roof shed and storage shed manufacturer in Kolkata, delivering practical structures with durable material selection, drainage planning and clean finishing.
▥
PPGL Roof Sheet
0.45 mm PPGL roof sheet is considered for attractive appearance and dependable weather protection.
↧
600 mm Dropping
Vertical dropping on all four sides improves rain protection and gives the roof shed a finished profile.
⌁
Outside Outlet
Water outlet is routed outside the shed for cleaner drainage and improved usability below the roof.
Technical specification for 1500 sq ft roof shed
- ColumnSHS 72 × 72 × 2.6
- TrussSHS 60 × 40 × 2, SHS 38 × 38 × 2.0
- PurlinSHS 60 × 40 × 2
- Base Plate10 mm
- Roof Sheet0.45 mm PPGL Sheet
- Material Weight1.5 kg per sq ft approx.
Cost details
Roof Sheet Area₹175/- per sq ft
Vertical Cladding₹100/- per sq ft
ScopeMaterials + Labour
₹2,75,625/-
Cost inclusive of materials and labour. GST extra. Final quotation depends on site access, roof level, fixing details, drainage scope and finishing requirement.
Roof shed applications
This 1500 sq ft roof shed is suitable for terrace storage, commercial coverage, service areas, utility spaces, residential terrace protection, small industrial roofing and weather-protected working zones.
- Terrace roof shed installation
- Storage shed and utility shed roofing
- Commercial roof coverage
- PPGL sheet roofing with MS/SHS structure
- Vertical cladding and drainage support
What affects roof shed cost?
Final roof shed cost depends on roof area, height, structure type, sheet thickness, vertical dropping, access to roof level, water outlet route, welding/fixing condition and finishing scope.
Early site review helps avoid leakage, poor drainage, weak anchoring and unnecessary material wastage.
Structured roof shed execution process
A planned process helps maintain cost clarity, practical drainage and reliable installation quality.
We review roof size, access, location, usage, height and preferred shed coverage.
SHS structure, purlin, truss, sheet, cladding and water outlet details are checked.
Area, material, labour and GST scope are clarified before final quotation.
Fabrication, fixing, sheet installation, vertical dropping and finishing are planned for site conditions.
Roof shed installation service areas
CND Engineering supports roof shed, storage shed, terrace shed, PPGL sheet roofing and steel structure requirements across Kolkata and major locations in West Bengal.
Frequently asked questions
Useful information for buyers comparing 1500 sq ft roof shed installation cost and technical specification.
What is the approximate budget for this 1500 sq ft roof shed?
The reference budget is ₹2,75,625 for roof work. Materials and labour are included, while GST and project-specific site items are extra.
Which roof sheet is used?
The reference specification uses 0.45 mm PPGL roof sheet with SHS tubular steel structure.
Is vertical dropping included?
Yes. The model includes 600 mm vertical dropping on all four sides for improved rain protection and finishing.
Which locations does CND Engineering serve?
CND Engineering serves Kolkata, Howrah, Hooghly, North 24 Parganas, South 24 Parganas, Haldia, Durgapur, Kharagpur and other locations in West Bengal and Eastern India.
Need a clear roof shed quotation?
Share your site size, preferred color and installation location. Our team will guide you with practical shed design and costing.
